BDM

Khanna Agro Industries has gained itself as a reputed Manufacturer, Trader, and Supplier in the field of harrow disc and other agriculture equipment, Since the year 2013, we are engaged in providing a large assortment of agricultural equipment and machines and have managed to garner a dominant name in the marketplace. Plain Disc, Notched Disc, Center Flat Disc, Flat Coulter, Dome Disc, etc are the few types of Agricultural equipment that we deal in. Below is the list of Plain Disc Size.

Category:

Description

DIA (INCH) (A) DIA (MM) THICKNESS CONCAVITY PACKAGING
INCH MM INCH MM MM DISCS PER BUNDLE
12 304.8 0.118 3 25 100
13 330.2 0.118 3 25 100
14 355.6 0.118 3 25 , 27 , 31 , 38 100
14 355.6 0.138 3.5 25 , 27 , 31 , 38 100
14 355.6 0.157 4 25 , 27 , 31 , 38 100
14 355.6 0.197 4.5 25 , 27 , 31 , 38 100
16 406.4 0.118 3 35 , 38 , 54 100
16 406.4 0.138 3.5 35 , 38 , 54 100
16 406.4 0.157 4 35 , 38 , 54 100
18 457.2 0.118 3 44 , 56 , 67 100
18 457.2 0.138 3.5 44 , 56 , 67 100
18 457.2 0.157 4 44 , 56 , 67 50
20 508 0.118 3 57 , 60 , 69 , 81 , 52 100
20 508 0.138 3.5 57 , 60 , 69 , 81 , 52 100
20 508 0.157 4 57 , 60 , 69 , 81 , 52 50
20 508 0.177 4.5 57 , 60 , 69 , 81 , 52 50
20 508 0.197 5 57 , 60 , 69 , 81 , 52 50
22 558.8 0.157 4 63 , 70 , 74 , 78 , 86 50
22 558.8 0.177 4.5 63 , 70 , 74 , 78 , 86 50
22 558.8 0.197 5 63 , 70 , 74 , 78 , 86 50
22 558.8 0.216 5.5 63 , 70 , 74 , 78 , 86 50
22 558.8 0.236 6 63 , 70 , 74 , 78 , 86 50
24 609.6 0.177 4.5 68 , 76 , 83 , 88 , 95 50
24 609.6 0.197 5 68 , 76 , 83 , 88 , 95 50
24 609.6 0.216 5.5 68 , 76 , 83 , 88 , 95 50
24 609.6 0.236 6 68 , 76 , 83 , 88 , 95 50
26 660.4 0.197 5 77 , 89 , 98 , 104 , 109 50
26 660.4 0.216 5.5 77 , 89 , 98 , 104 , 109 50
26 660.4 0.236 6 77 , 89 , 98 , 104 , 109 50
26 660.4 0.256 6.5 77 , 89 , 98 , 104 , 109 50
28 711.2 0.236 6 95 , 109 52
28 711.2 0.256 6.5 95 , 109 52
28 711.2 0.2756 7 95 , 109 25
28 711.2 0.295 7.5 95 , 109 25
28 711.2 0.315 8 95 , 109 25
28 711.2 0.354 9 95 , 109 25
28 711.2 0.393 10 95 , 109 25
